KBP Series Seawater Pump

KBP seawater pump is a series of sturdy and durable pump with high head and sufficient flow. The body has strong sealing, corrosion resistance and pressure resistance.Suitable for all kinds of aquaculture ponds and seawater ponds.

Features

Protection: IP55.

Large flow rate.

Low noise level.

Max. working pressure:6.0bar

Shaft: Stainless steel 316.

Mechanical seal: Graphite / Ceramic seal.

Detail

Resource

Specification
Manual

Model	Q-Max(m³/h)	H-max(m)	Rated power supply	Input power		Length(mm)	Width(mm)	Height(mm)	Connection size	Weight(kg)	Packing Size(mm)
Model	Q-Max(m³/h)	H-max(m)	Rated power supply	kW	HP	Length(mm)	Width(mm)	Height(mm)	Connection size	Weight(kg)	Packing Size(mm)
WL-KBP400	50	18	380V/50Hz	3	4	750	221	373	2"/63mm	30	775315450
WL-KBP500	55	20	380V/50Hz	3.7	5	750	221	373	2"/63mm	30	775315450
WL-KBP550	60	20	380V/50Hz	4	5.5	770	221	373	2.5"/75mm 3"/90mm	33	830315440
WL-KBP750	70	22	380V/50Hz	5.5	7.5	780	221	373	2.5"/75mm 3"/90mm	37	830315440
