SSPE Series FRP Strainer

Basket strainer is used as pre-filter to remove hair, fiber and large suspended solids in water, to protect the pump and ensure the normal operation of the whole water treatment system.

Features

- Stainless steel body and filter basket, high strength and corrosion resistance, suitable for seawater environment.

- Quick open design, convenient for cleaning and maintenance.

- Standard flange connection for easy installation.

- Clear lid with easy access allows for simple visibility of debris.

- Customizable dimensions and features.

Detail

Operating principle

The strainer is equipped with a built in filter basket. When the raw water passes through, the solid impurity particles are blocked in the strainer and the clean water flows out. The bottom provided with a sewage outlet, the debris, hair, fibers and other big impurities could be drained from here, and the filter basket can be removed from inside for cleaning.

Resource

Specification
Manual

High inlet and low outlet type

Model	Diameter D(mm)	Height H(mm)	Height of water inlet H1(mm)	Height of water outlet H2(mm)	Water inlet size DN(mm)	Water outlet size DN(mm)	Width L(mm)
WL-SSGF159	159	250	165	85	DN32	DN32	359
WL-SSGF159	159	250	165	85	DN40	DN40	359
WL-SSGF159	159	250	165	85	DN50	DN50	359
WL-SSGF219	219	350	230	120	DN65	DN65	419
WL-SSGF219	219	350	230	120	DN80	DN80	419
WL-SSGF273	273	400	265	135	DN100	DN100	473
WL-SSGF273	273	400	265	135	DN125	DN125	473
WL-SSGF273	273	400	265	135	DN150	DN150	473
WL-SSGF325	325	490	330	160	DN200	DN200	525
WL-SSGF400	400	520	340	160	DN250	DN250	600

Parallet inlet and outlet type

Model	Diameter D(mm)	Height H(mm)	Height of water inlet H1(mm)	Height of water outlet H2(mm)	Water inlet size DN(mm)	Water outlet size DN(mm)	Width L(mm)
WL-SSPF159	159	250	125	125	DN32	DN32	359
WL-SSPF159	159	250	125	125	DN40	DN40	359
WL-SSPF159	159	250	125	125	DN50	DN50	359
WL-SSPF219	219	350	175	175	DN65	DN65	419
WL-SSPF219	219	350	175	175	DN80	DN80	419
WL-SSPF273	273	400	200	200	DN100	DN100	473
WL-SSPF273	273	400	200	200	DN125	DN125	473
WL-SSPF273	273	400	200	200	DN150	DN150	473
WL-SSPF325	325	490	246	246	DN200	DN200	525
WL-SSPF400	400	520	260	260	DN250	DN250	600
