WL-DE
LASWIM
84212110
D.E is historically the media of choice for the designers of some of the largest and most beautiful pools in the word,it is now more practical for all backyard pools as well. It brings you the proven performance of diatomanceousearth media in the word's safest and easiest-to-operate filter.
The greater cycle times and minimized maintenance of the filter,coupled with superior grid system,gives you the finest D.E.filter available.
1.Good and crude media for filtration-Diatomaceous(D.E.)
2.High Filter precision,can reach 2~3μm.
3.Shorter time to backwash,save water and energy sources.
4."Deep bed"designed, save area.
Product Parameters
Model | Pipe Size | Filtration area | Design flow | Required D.E(kg) | Tank Diameter(mm) | Tank Height(mm) | |||
inches | mm | m² | Ft² | m³/h | lpm | ||||
WL-DE650 | 2 | 63 | 3.64 | 39 | 18 | 300 | 2.2 | 635 | 1310 |
WL-DE700 | 2 | 63 | 5.07 | 55 | 25 | 417 | 3 | 700 | 1340 |
Model | Pipe Size | Filtration area | Design flow | Required D.E(kg) | Tank Diameter(mm) | Tank Height(mm) | |||
inches | m² | Ft² | m³/h | lpm | |||||
WL-DE800 | 90 | 9.4 | 101 | 47 | 783 | 5 | 800 | 2100 | |
WL-DE900 | 90 | 11 | 118 | 55 | 916 | 6 | 900 | 2100 | |
WL-DE1000 | 110 | 15 | 161 | 75 | 1250 | 8 | 1000 | 2100 | |
WL-DE1200 | 110 | 23.4 | 252 | 117 | 1949 | 13 | 1200 | 2300 | |
WL-DE1400 | 160 | 32.6 | 351 | 163 | 2716 | 19 | 1400 | 2350 | |
WL-DE1600 | 160 | 40.6 | 437 | 203 | 3382 | 22 | 1600 | 2350 | |
WL-DE1800 | 200 | 53.4 | 575 | 267 | 4448 | 30 | 1800 | 2450 |
D.E is historically the media of choice for the designers of some of the largest and most beautiful pools in the word,it is now more practical for all backyard pools as well. It brings you the proven performance of diatomanceousearth media in the word's safest and easiest-to-operate filter.
The greater cycle times and minimized maintenance of the filter,coupled with superior grid system,gives you the finest D.E.filter available.
1.Good and crude media for filtration-Diatomaceous(D.E.)
2.High Filter precision,can reach 2~3μm.
3.Shorter time to backwash,save water and energy sources.
4."Deep bed"designed, save area.
Product Parameters
Model | Pipe Size | Filtration area | Design flow | Required D.E(kg) | Tank Diameter(mm) | Tank Height(mm) | |||
inches | mm | m² | Ft² | m³/h | lpm | ||||
WL-DE650 | 2 | 63 | 3.64 | 39 | 18 | 300 | 2.2 | 635 | 1310 |
WL-DE700 | 2 | 63 | 5.07 | 55 | 25 | 417 | 3 | 700 | 1340 |
Model | Pipe Size | Filtration area | Design flow | Required D.E(kg) | Tank Diameter(mm) | Tank Height(mm) | |||
inches | m² | Ft² | m³/h | lpm | |||||
WL-DE800 | 90 | 9.4 | 101 | 47 | 783 | 5 | 800 | 2100 | |
WL-DE900 | 90 | 11 | 118 | 55 | 916 | 6 | 900 | 2100 | |
WL-DE1000 | 110 | 15 | 161 | 75 | 1250 | 8 | 1000 | 2100 | |
WL-DE1200 | 110 | 23.4 | 252 | 117 | 1949 | 13 | 1200 | 2300 | |
WL-DE1400 | 160 | 32.6 | 351 | 163 | 2716 | 19 | 1400 | 2350 | |
WL-DE1600 | 160 | 40.6 | 437 | 203 | 3382 | 22 | 1600 | 2350 | |
WL-DE1800 | 200 | 53.4 | 575 | 267 | 4448 | 30 | 1800 | 2450 |
