SWIMMING POOL DISINFECTING EQUIPMENT

Views: 9     Author: Site Editor     Publish Time: 2022-11-24      Origin: Site

DISINFECTING EQUIPMENT HQ/SQ SALT CHLORINATOR
HQ/SQ salt chlorinator improve your pool water quality by using harmless table salt, instead of using harsh chemicals, it is reliable, low maintenance, much more safety to health. Easy and simple programming and fully automatic operation lets you enjoy a relaxed swimming time.
Salt chlorinators are an alternative means of sanitizing your pool with chlorine by electrolysis process. The electrolysis process is achieved by passing the salty water through an electrolytic cell, sodium chlorine in the water is converted into chlorine to achieve pool water disinfection.

WechatIMG2


Features:
1.Self clean function:by reverse the polarity automatically,which prevents calcium from accumulating and therefore prolong the cell's lifetime.
2.Six different chlorine output control:easy adjustment of chlorine level,to meet demand of different time,this will save energy environment friendly.
3.HQ salt chlorinators are equipped with timer for pump and timer for underwater light.
4.Smart cooling:the cooling intensity can be adjustment according to the temperature inside the control box.
5.Protect from no adequate water causing the generator or cell destroyed.
6.Two optional outlets make the installation more convenient.
7.Overheat protection:prolong the control system life span.
8.Datachable titanium panels are easy to install,clean and maintain.
9.Alarm system:automatic protection for your system and pool if over-salting occurs or salt level is too low.
10.Temperature sensor could be changed separately,reduce the maintenance cost.

WechatIMG3

Model Electrolytic cell dimensions LxWxH(mm) Max Chlorine Output(g/h) Voltage(V) Total power(W) Pump power(Max) Light power(Max) Max Pool Volume(m3)
HQ20 365*260*140 16 AC220-240V 1.70KW 1.5KW/6.8A AC12V/100W 68
HQ30 365*260*140 25 AC220-240V 1.75KW 1.5KW/6.8A AC12V/100W 105
HQ40 365*260*140 33 AC220-240V 1.80KW 1.5KW/6.8A AC12V/100W 140
HQ50 365*260*140 42 AC220-240V 1.85KW 1.5KW/6.8A AC12V/100W 175
SQ20 365*260*140 16 AC220-240V 0.25KW / / 68
SQ30 365*260*140 25 AC220-240V 0.25KW / / 105
SQ40 365*260*140 33 AC220-240V 0.25KW / / 140
SQ50 365*260*140 42 AC220-240V 0.25KW / / 175

Note:In practice,the local pool standards and professional habits should be considered,and the adjusting allowance of 20-30% should be reserved.
For outdoor pool,cyanuric acid(stabilizer)should be added to pool water,the ideal range for cyanuric acid is 25-50ppm when used.
